24v電源輸出模塊
Electrical
? High efficiency: 91.9% @ full load
? Fixed frequency operation
? Input UVLO, OTP and output OCP, OVP
? Output voltage trim: max 20%
? Pre-biased startup
? 2250V isolation and basic insulation
?Applied to altitude up to 5000m
Mechanical
? Open-frame:
Size: 33.0mm(L)x22.8mm(W)x9.2mm(H)
? With heat spreader:
Size: 33.0mm(L)x22.8mm(W)x12.2mm(H)
Safety & Reliability
? IEC/EN/UL/CSA 62368-1, 2nd edition
? ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS18001 certified manufacturing facility
